Features:

• IP68 Rating.
• 2-Year Warranty.
• Marine-grade construction.
• Overcurrent limit.
• High voltage safety.
• Reverse connection protection.
• Temperature protection.
• Full-Auto timing shutdown.
• Anti-Walking function.
• LED indicator for Charging Process.
• CAN communication (optional).
• 12V5A Auxiliary power supply (optional).

Safety:

• Short-Circuit: Yes
• Open-Circuit: Yes
• Overheating: Yes
• Overcharge: Yes
• Spark-Proof: Yes
• Reverse Polarity: Yes

Size:

• Height: 6.5 Inches (165.1mm)
• Width: 7.9 Inches (201.3mm)
• Depth: 2.2 Inches (56.0mm)
• Weight: 6.1 Pounds (2.7kg)

Operating Requirements:

• Line Voltage: 120V to 240V AC
• Frequency: 50Hz to 60Hz
• Operating Temperature: -4° to 104° F (-20° to 50° C)
• Storage Temperature: -22° to 140° F (-30° to 60° C)
• Relative Humidity: 0 to 95% Non-Condensing

Cord Management:

• DC Cable + Eyelet Length: 72 Inches (182cm)
• DC Cable Size: 16 AWG
• DC Fuse Size: 7.5 AMP MINI ® Blade Fuse
• AC Cable Length: 72 Inches (182cm)
• AC Cable Size: 18 AWG
• Oil, gas, grease, water, chemical, UV, abrasion resistant
